Features

• Improvements to Display Effect
• Pixel level brightness and chroma calibration Work with NovaStar’s high-precision calibration system to calibrate the brightness and chroma of each pixel, effectively removing brightness differences and chroma differences, and enabling high brightness consistency and chroma consistency

• Quick adjustment of dark or bright lines

  The dark or bright lines caused by splicing of modules or cabinets can be adjusted to improve the visual experience. The adjustment is easy and takes effect immediately.

  3D function

  Working with the sending card that supports 3D function, the receiving card supports 3D outpu

Improvements to Maintainability

NovaLCT V5.2.0 or later is required.

Firmware program readback
The receiving card firmware program can be read back and saved to the local computer.

NovaLCT V5.2.0 or later is required.

Configuration parameter readback
The receiving card configuration parameters can be read back and saved to the local computer.

Quick uploading of calibration coefficients Upload the calibration coefficients quickly to the receiving cards to improve efficiency.

• Setting of a pre-stored image in receiving card The image displayed during startup, or displayed when the Ethernet cable is disconnected or there is no video signal can be customized.

• Temperature and voltage monitoring
  The receiving card temperature and voltage can be monitored without using peripherals.

• Cabinet LCD
  The LCD module connected to the cabinet can display the temperature, voltage, single run time and total run time of the receiving card.

•   Bit error detection
  The Ethernet port communication quality of the receiving card can be monitored and the number of erroneous packets can be recorded to help troubleshoot network communication problems
